3hp 1 Speed Aqua-flo XP2e Pump (2"x 2")

3HP 1 Speed Aqua-flo XP2e Pump (2"x 2")

This 3hp Aqua-flo XP2e Pump is from Aqua-flo's Flomaster range of pumps designed specifically for hot tubs and spas. The XP2e is a direct replacement for the older model XP2 as it has the same wet end dimensions but offers greater water flow. This pump is definitely one of the most common Aqua-flo spa pumps and used by many hot tub brands over the years. A powerful pump but economic with an efficient 3hp 80 frame sized Italian EMG motor designed for Europe and to replace Aqua-flo pumps with USA smooth bodied motors such as Emerson where space allows within the spa's cabinet.

This exact Aqua-Flo XP2e pump can be found on Spa brands such as Aegean, Master Spa, Sunrise Spas, Artesian, Cal Spas, Clearwater, Coleman Spas, La Spas, Gulf Coast, Saratoga, Marquis Spas, Vita Spas and many more.

Aqua-flo XP2e Pump Overview

• This is a 1-speed pump so the single high speed is used for JETS or Boost operation when bathing in your spa or Hot Tub.
• XP2e Pump wet end connects to 2-inch plumbing unions on the inlet and outlet. Both connections have a 78mm outside thread diameter and you can use 2 inch flat gaskets to seal the connections.
• Wet end can be rotated from the standard 12 O'clock position to 3 O'clock or 9 O'clock position easily by removing the four 5/16 bolts that attach the wet end to the EMG motor.
• Wiring - This replacement Aqua-flo XP2e Pump is NOT supplied with a new cable so you will need to swap over from your old existing Aqua-flo pump. You will have three wires, live for the high speed (Red, Brown or Black). Neutral (Blue or White) and Earth (Green). If you need a new cable for your new pump then see related products.

Spa Pump Specifications

• Manufacturer - Aqua-flo (Gecko)
• Part Number - 05253000-6040
• Model - XP2e 3hp
• Type of Product - Hot Tub / Spa Pump
• Number of Speeds - 1 (high speed)
• Motor & Wet End Frame Size - 56 Frame
• Horse Power - Motor 3HP
• Amps Low/High - N/A/10.3
• KW Low/High - N/A/2.4
• RPM Low/High - N/A/2840
• Hz - 50
• Dimensions (MM) - Length: 378, Height: 203, Width: 200

We Are Here To Help!

It can be a bit confusing choosing your new pump as brand names and models are not always written on them. The quickest way is to simply send us some images of the Aqua-flo XP2e pump you are replacing through our Contact us page and let us do the work for you.
