Balboa Bundle - BP200G1 3kw & TP400 4 Button Topside Control

Balboa's BP series systems are the most technologically advanced spa control systems ever manufactured, affordable, and super reliable.

Our Balboa BP200G1 spa control system bundle benefits from having a compact control box, wifi capability, a 3kw m7 heater, and a narrow oval TP400 touch panel which is perfect for fitting in tight spaces on a spa shell. The BP600G1 control box can run 1 pump with two speeds or a one-speed jet pump if a dedicated circulation pump is used for the spa's heating and filtration. In addition, the BP200G1 system can be expanded to run an additional pump or air blower by installing one of these expander PCB's (Blower or Pump).

This Balboa bundle can be retro-fitted to many spas and used for upgrading from a Chinese spa control system or updating an old unserviceable one where parts are unobtainable. Due to this system having a 3kw heater and being able to run this many electrical components, you will need to have a 16 amp supply to it from your home consumer unit so you may need an electrician to wire this for you if you don't already have this installed.

This Bundle Can Operate:

• Pump 1 - Two Speed (One speed if using circulation pump)
• Pump 2 or Blower (Only with additional expander PCB installed)
• Circulation pump - Optional
• 12 Volt light (on/off)
• 3kw M7 heater
• Ozonator
• Wifi Capability (Wifi module required)

This Bundle Contains:

• BP200G1 Wifi ready control box with 3kw M7 heater assembly.
• Long/narrow 4 button oval TP400 topside touch control pad which has buttons: JETS, TEMP, LIGHT, AUX
• Topside control panel dimensions, Length: 210mm x Width: 63mm.

Dimensions

• Length: 435 mm (inc heater) 330 mm (box only)
• Width: 160 mm
• Height: 220 mm
• Topside: 210mm x 63mm

Features

• Lowest cost entry-level BP System
• BP capable features
• Compact size with removable feet
• Attached or remote heater
• WiFi (bwa™ & ControlMySpa™), Balboa Bluetooth Audio (bba™), Newest TP/SpaTouch™ Panels
• Can be customized to fit your needs

WIFI Capability

All Balboa's BP series systems are all WIFI ready and all you need to do to benefit from this functionality is to buy is a Wifi Receiver Module. Connect the wifi module up to your BP series control box and download the Balboa Worldwide APP which is available for Android and IOS devices. The BWA App allows you to access your hot tub via a direct connection anywhere in the local proximity of your tub, anywhere in your house that you can connect to your local WiFi network, or anywhere in the world you have an internet connection to your smart device via 3G, 4G, or WiFi hot spots. Allowing you to control your spas filtration, heat settings, and electrical components remotely via a smartphone or tablet.

Balboa's M7 Technology

The latest Balboa BP series control boxes all come with M7 technology, so you don't need to integrate external temperature sensors into the spa or pressure switches to determine water flow. In this technology, two M7 sensors are employed, one at each end of the heater assembly, which provide a superior method to detect water flow and temperature at the same time.

Product Manuals

We have included the TP400 operation manual, wifi module setup, and other useful info regarding the BP200G1 system.

• Balboa BP200UX Tech Sheet
• TP400/600 User Guide
• Wifi 123 Easy Installation Guide
• BWA App User Guide
• BWA Welcome Guide

Need Help?

We have been replacing spa control systems for many years so we know what replaces what so if you are unsure which one to use just email us through our contact us page with images of the current setup, we will be more than happy to help you.
